The Skycom CE control is intended for opening of skylights, smoke hatches, ... for Smoke and Heat Extraction (SHE)
and comfort ventilation of 1 fire zone.
Generally the fire zone is controlled by 1 Skycom CE MASTER control and as many Skycom CE SLAVE controls as
there are opening systems. So each opening system needs its own Skycom CE Slave control (except with opening sys-
tems with mechanical positive safety).
The Skycom CE control has the following operation possibilities:
Operation for Smoke and Heat Extraction (control in Alarm-status):
1. Automatically activated: by smoke or heat detectors. Each control has also an internal T-sensor which generates
alarm at 75°C.
2. Activated by passer-by: on 'break-glass' fire-switches (on control or external)
3. Operation by firemen: possibility for priority open and close on the control OR on an external priority switch for
firemen
Operation for comfort ventilation:
Activated by open-close switches (on control or external) or by weekly timer, room thermostat,
outdoor weather sensor.
The operation status (OK / Alarm / Fault / Window open) is indicated by Led's and is also available on outputs for connec-
tion with other systems (AFA-systems, Air-gates, buzzer, ...) in the building.
We advise to consult your fire department to choose the best installation place for the Skycom CE Master control.
Generally install the Skycom CE Master control at a visible place and easy to be reached, on the access road of the fire-
men with the bottom at 1,35 - 1,45 m above the floor in the entrance hall of the (main) building.
When for some reason the master control can not be installed on the best accessible place for the firemen, you can
install the external priority switch for firemen instead. In such cases the Master control will be installed in a technical
room.
The Skycom CE Slave control must be installed as close as possible (max. 5 m) to the opening system, i.e. at the ceil-
ing of the building or against the roof opening. The Slave detection unit must not always be installed. For some opening
systems, the legal requirement of the positive safety is obtained mechanically (Skymax
unit for systems without integrated temperature sensor (Skylux
The control unit weights 7,5 kg and must be installed on a stable underground. The mounting holes for wall mounting
are placed on the metal plate underneath the plastic lid.
Foresee (at least) a separate 230V power circuit with its own automatic circuit breaker for each fire zone. Don't connect
other devices to this circuit!
It is sometimes required to supply the control unit with a 230V circuit with separate earth leakage circuit breaker and that
a circuit breaker is installed on the actuator line.
SKYCOM CE
SHE-CONTROL

GENERAL DESCRIPTION

INSTALLATION

160° / Cintramax
®
AG.PLASTICS QUALITY
info@agp.be
www.agp.be
). Use always a Slave detection
®
/ Skyvent ).
® ®
