Skycom CE Master Benutzerhandbuch Seite 52

Skycom CE 24V - 8A
Master / Slave
24V
+
-
+
-
18
SKYCOM CE
FIRE VENTILATION CONTROL
Red 2,5mm2
Black 2,5mm2
- 24VDC +
N1
PE L1
Blue
M1
Brown
AG.PLASTICS QUALITY
BUZZER
Max. 8A
FUSE F1 - fast
Actuator
Motor line monitor
J2
Ext 3 wire monitor (line 1)
4
J3
3
Motor
2
1
1 2 3
+ -
Line 1
Actuator
24V Out
2
1
5 7
M2
6 8
3
4
Next LIP
info@agp.be
www.agp.be
RED
ALARM
YEL
FAILURE
BUZZER ON/OFF
J1
RESET
YEL YEL
AC FAIL LINE FAIL
BLUE
DOME OPEN
Without keyboard jumper mounted
Alarm Out Failure Out
4 5 6 7 8 9
GRE
OK
LED 1 Smok
LED 2 Smok
LED 3 Wind
LED 4 Line
LED 5
Flash
LED 6 Line
LED 7 Bus-s
Flash
Max.
YEL
BATT LOW
NTC
Foil
Fire switch
10 11 12 13 14
3 6
2 4 7
1
2,2 kΩ
10 KΩ J1
Manual control point.
Break glass (BVT) No. 1
3 4 6
1 2 7
6
2 3 4 7
1
2,2 kΩ
10 KΩ
J1
Last manual control
point
Break glass (BVT)
Fit Jumper J1 for line
monitoring
