RICOO FS304 Montageanleitung Seite 9

Please check BEFORE installation distance between VESA mounting holes on your display!
!
This wall mount supports the following distance between holes:
Horizontally
Vertical / Perpendicularly
FS304
all color variations
TV STAND
VESA-Mounting holes
Vertical /
Perpendicularly
Horizintally
min. 30mm - max. 425mm
min. 75mm - max. 400mm
400x100
100x100
200x100 400x200
400x300
200x200
400x400
300x200
300x300
1
INSTALLATION MANUAL
CAUTION: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
Display back
40kg
(88lbs)
MAX
