ERGOMETRICS CT 870 PRO Handbuch Seite 8

Step 2
1. Assemble the seat (10) to the adjustable seat tube (11) as shown on fig a.
2. Put the seat post (9) into the main frame (1). And adjust the seat post up and down via the ball knob
(31) shown as fig. b.
3. The user could adjust the seat (10) backward and frontward by adjusting the screw knob (18) shown as
fig. c.
11
17
18
9
31
1
a
b
c
8
10
11
