Part List - ERGOMETRICS CT 870 PRO Handbuch

Partlist
Part No. Description
1 Main frame
2 Rear stabilizer
3 Adjustable foot cap
4 Front stabilizer
5L Left foot cap
5R Right foot cap
6 Domed nut M8*1.25*15L
7 Square neck bolt
M8*1.25*90L
8 Oval cap 25*50*32L
9 Seat post
10 Seat
11 Adjustable seat tube
14 Screw ST4*1.41*20L
15 Adapter
16 Foam (HDR) D30*5.0T*575L
17 Flat washer D25*D8.5*2T
18 Screw knob D60*32L
(M8*1.25)
19 Mushroom Cap D1/1/4"*29L
20 Allen bolt M8*1.25*20L
21 Multi-groove belt 1066 PJ6
22 Waved washer D22*D17*0.3T
23 Flat washer D23*D17.2*1.5T
24 Round magnetic
25 Left chain cover
26 Right chain cover
27 Belt wheel
28 Upper protective cover
29 Handlebar post
30 Handle pulse
Handle pulse cable 600L
31 Ball knob D50*M16*32*D8
32 Nylon nut M8*1.25*8T
33 Bolt cap D23*6.5
34 Bolt M8*1.25*25
35L Left crank
35R Right crank
36 Handlebar
37 T-shaped knob M8*1.25*65
38 Computer SE6630-71
39 Flat washer D13*D6.5*1.0T
Q'ty Part No.
1 40 Upper computer cable 1000L
1 41L Left computer bracket
2 41R Right computer bracket
1 42 Cover 80.6*56*52.5
1 43 Flat washer D16*D8.5*1.2T
1 44 Spring washer D15.4*D8.2*2T
4 45 Bushing D8.2*D12.7*33
4 46L/46R Pedal
2 47 C-ring S-17 (1T)
1 48 Protective ring for chain cover
1 49 Bolt M6*1.0*15L
1 50 Bearing #99502
2 51 Spring washer D15.4*D8.2*2T
1 52 Crank axle
2 53 Curved washer D22*D8.5*1.5T
1 54 Sensor cable 500L
1 55 Bearing #6003ZZ
2 56 Screw M6*1.0*15L
4 57 Flat washer D25*D8.5*2T
1 58 Fixing plate for idle wheel
2 59 Screw M5*10L
1 60 Plastic flat washer D50*D10*1.0T
1 61 Bearing #99502
1 62 Screw ST4*1.41*15L
1 63 Spacer D22.5*D17.2*6.4T
1 64 Electric magnetic system
1 65 Lower computer cable 600L
1 66 Electric cable 600L
2 67 Nylon nut M6*1.0*6T
2 68 Spring D2.2*D14*65L
1 69 Screw ST4*1.41*15L
1 70 Inner tube D66*D50.3*170L
2 71 Resistance board
2 72 Inner tube D71.5*100L
1 73 Plastic cap D3*30L
1 74 C-clip S-16 (1T)
1 75 Nut M8*1.25*6T
1 76 Waved washer D21*D16.2*0.3T
1 77 Screw M8*1.25*25L
4 78 Spring washer D10.5*D6.1*1.3T
79 Buffer D9*D5.8*13
6
Description Q'ty
1
1
1
1
1
1
1
1
1
1
4
2
8
1
8
1
2
4
1
1
4
2
2
3
1
1
1
1
4
1
2
1
1
1
2
1
1
1
1
4
1
