Sealing Bumper Pads
To help create a seal between caravan and awning there are sealing bumper pads (15)
sewn to the rear panels. Using the rear pegging points, these bumpers should be pulled
towards the caravan. An improved seal can be maintained by use of the optional rear
upright pole set. Insert the top of each pole into the pocket in the top rear corners (15a),
adjust the height to bring the pole under tension (15b) and then secure the pole to the
bumper pads using the tie tapes.
Draught Skirt
The supplied draught skirt should be pulled through the awning rail at the bottom of your
caravan (13). The ropes at the top corners can be tied to the caravan chassis to make the
skirt taut (13a).
Curtains & Blinds
The Rally AIR and Fiesta AIR Pro have blinds to cover the front windows that can be rolled
down into pockets at the bottom of the windows.
The Rally AIR Pro and Ace AIR have two curtains to cover each window panel. They have
curtain runners along their top edge that simply slide onto the curtain track sewn above
each window (14).
Use the plastic retainers to keep the curtains tidy during the day. The blinds on the side
windows roll to the side on the Rally AIR.
Mud Skirt
Kampa® AIR awnings come with an internal mud skirt to keep out draughts. You can lay
your carpet or groundsheet on top of this skirt.
Storm Tie-Down Kit
The guy lines should be utilised at all times. However, for extra security an optional Storm
Tie-Down Kit is available. Attach each tie-down to the side release buckle already sewn to
the awning (16a). At the other end of the tie down you will find a metal 'D' ring. Attach the
hook, connected to the tension band, to the 'D' ring and then peg the tension band using
the large peg supplied or another suitable peg (16b). Ensure that the storm strap is pegged
under tension but not so that it distorts the shape of the awning. The tie-downs should
always be used in pairs.
Deflation
To pack away the awning:
1. Inspect the awning to ensure that all the interior isolation valves are open (these
usually remain open and do not normally need to be adjusted).
2. Close all doors and openings.
3. Close all window blinds or remove curtains.
4. Un-peg the Quickpitch webbing guy lines and, if fitted, the tie down kit.
5. Un-peg the intermediate pegging points but keep the four corners in place.
AWN-AIR-UM-0715
(Optional Extra)
