Parameterization

7.8 Object 0xF6, Ethernet Link

The Ethernet Link Object maintains link-specific counters and status information
for an Ethernet 802.3 communications interface. The measuring system supports
exactly one instance of the Ethernet Link Object for each Ethernet IEEE 802.3
communications interface on the module. The measuring system possesses two ports
and thus two Ethernet link object instances.

7.8.1 Common Services

Service Code
0x0E
0x10

7.8.2 Class specific Services

Service Code
0x4C

7.8.3 Class Attributes

Nr. Access Name
1 Get Revision
2 Get Max Instance
Number of
3 Get
Instances
Table 22: Ethernet Link, Overview of the class attributes
 TR-Electronic GmbH 2013, All Rights Reserved
Page 162 of 175
Service Name
Get_Attribute_Single
Set_Attribute_Single
Service Name
Get_and_Clear
Data type Attribute Description
UINT Revision of this object
Maximum instance number of an
UINT object currently created in this class
level of the device.
Number of object instances
UINT currently created at this class level
of the device.
TR - ECE - BA - DGB - 0102 - 08
Description
Returns the contents of the specified
attribute.
Modifies the contents of the specified
attribute.
Description
Gets then clears the specified attribute
(Interface Counters or Media Counters).
Printed in the Federal Republic of Germany
Default
0x0003
0x0002
0x0002
