T22
Torque M in %
nom
+M 100
nom
45
0
35
−M 100
nom
Fig. 4.1 Permissible dynamic loading
4.2 Maximum rotational speed
The T22 torque transducer allows torque measurements of 9000 rpm up to
16000 rpm, depending on the measuring range. Limit values see
5

Displaying torque

Torque
If a clockwise torque is applied, there is a positive output signal (0...+5 V,
respectively +10...+18 mA).
6

Maintenance

The T22 torque transducer is largely maintenance free. We recommend that
the low-friction special bearing should be replaced at the Darmstadt factory,
after approx. 20 000 working hours. The calibration will also be checked at this
time.
A2302-2.0 en/de
Upper torque limit
80 % M
nom
vibration bandwidth
Lower torque limit
Chapter 8.
13
HBM
