no light - instrument fuses
defective
- plug not connected to
mains supply
- light source not
switched on
- lamp defective
- transformer defective

4. MAINTENANCE AND CLEANING

4.1 Halogen lamp replacement
CAUTION:
The Halogen lamp should be cooled down due to risk of burning!
Afterwards remove lamp from lampholder with a fabric.
a) Set the power switch (10) off, then the 0 is visible and disconnect the mains cable
(1) from the appliance plug socket (20) and from the mains.
b) Push the sliding lock (6) aback, open the top cover (7).
c) Using a cloth, remove the defective halogen lamp (14) with the lamp socket (15)
from the lamp holder (13) and disconnect it from the lamp socket (15) .
d) Replace the halogen lamp (14) with a new one of the identical type. Connect it to
the lamp socket (15) and place it in the lamp holder (13). Push the new lamp
down into the lamp holder (13) to a positive stop. Do not touch the quartz or
the inside of the reflector.
e) Close the top cover (7). Push the sliding lock (6) to the rear then forward
to lock the top cover (7).
f) Connect the mains cable (1) to the appliance plug socket (20) and to the mains
supply.
g) Set the power switch (10) on, then the 0 is not visible .
4.2

Fuse replacement

a) Set the power switch (10) off, then the 0 is not visible. Disconnect the mains
cable (1) from the appliance plug socket (20) and the mains supply.
- replace fuses
- connect plug
- switch on light
source
- replace lamp
- return instrument to
supplier
See paragraph 4.2
see paragraph 4.1
13
