2. DESCRIPTION OF INSTRUMENT
2.1 Application
®
The intralux 5100
Stereo Microscopes and fulfils the most demanding requirements concerning safety and
performance.
2.2 Features of the instrument
To satisfy increasing demands for lighting with high colour fidelity, the
been equipped with a specially developed crescent shaped diaphragm giving manually
operated brightness control which does not alter the colour temperature of the lighting.
In addition to the mechanical light regulation there is an electrical 8 steps switch
built-in which allows to reduce the secondary lamp voltage from 110 to 75% which
increases the average lamp lifetime, but decreases the colour temperature:
110% intensity 100h / 105% 140h / 100% 200h / 95% 310h / 90% 520h / 85% 900h / 80%
1'700h / 75% 3'600h (calculated values in continuous operation
The electrical reduction of the light intensity increases the lamp lifetime
considerably! Therefore we recommend to work on 80 or 85% intensity setting.
2.3

Scope of supply

®
-
intralux 5100
- Filterholder blank
- Power cable EURO-Schuko, CHF, USA (cable with GB is not available)
2.4 Used Symbos
Caution
(refer to accompanying documents) used to direct the user to the
instruction manual where it is necessary to follow certain specified
instructions where safety is involved.
In case of non-observance
- persons could put at risk
could cause disfunction or device-damage
-
Heat
Lamps and heat sinks may emit extreme amounts of heat during and
after operation. Approach and handle these and other potentially hot
components with caution.
3. STARTING UP AND OPERATION
cold light source has been specially developed for the illumination of
®
intralux 5100
)
has
