LEGEND Description
1 Mains cable
2 Filter holder without filter (colour filters on request)
3 Filter holder receptacle
4 Light guide receptacle
5 Carrying handle
6 Sliding lock
7 Top cover
8 Brightness control knob (crescent shaped diaphragm)
9 Intensity control knob (electrical lamp intensity setting, 8 steps)
10 Power switch
11 Type plate
12 Warning plate
13 Lamp holder
14 Halogen reflector lamp PN 23500.014
15 Lamp socket PN 10435.110
16 Lamp socket connector
17 Fan (DC)
18 Fuse holder
19 Fuses (1pc. active, 1pc. Spare) for:
• 230V mains: 2A slow blow 250V PN 90045.112
• 120V and 100V mains: 4A slow blow 250V PN 90045.115
20 Appliance plug socket
