• Quantum 120 and Quantum
®
re hybrid wheel unit from its support.
• Quantum 220: In general, we recommend you do not remove the hy-
®
brid wheel unit from the motor block. If it is necessary, then lift it care-
fully with two flathead screwdrivers on opposite sides. After cleaning,
the unit must be inserted back into the motor block by applying some
even but increased pressure. You can feel it when it audibly engages.
Then, use a flathead screwdriver to lift the hybrid wheel slightly so
that you have a space of approx. 2-3mm (1/12 in) between the hybrid
wheel and the motor block.
Step 4: Cleaning and care of pump and skimmer
• Now, the skimmer is completely disassembled and it can be clea-
ned. It is recommended to use tap water for cleaning (do not use any
detergent). Any hard to clean crusts and lime scale deposits can be
removed by placing it in a solution of 10% citric acid. Subsequently,
rinse it well with water.
• Use silicon grease regularly on the rubber seals.
Step 5: Assembly of pump and skimmer
• Assemble all parts of the skimmer in the corresponding order.
• INFORMATION on Quantum
unit and assembling the pump, pay close attention to the instructions
under step 3.
160: In this case, you can pull the enti-
®
220: When placing the hybrid wheel
®
