705-DCBLDHTX-L (MJ30-250/200)

13
6
10
9
3
7
15
ITEM PART NUMBER DESCRIPTION
OVERLAP FOR BLADE 250xDia
1 BLD-25025-OVL
25
Twist Blade 250xDia 25
2 BLD-25025T-10AC
(Anti_Clk)
3 BLDB-294-25 BLADE BACK (294 CTR 25 deg)
CROSS BLADE BACK (315 CTR
4 BLDBX-315-25
25 deg)
5 BLDBXT-315-30 OVERLAPPER MOUNT
6 DF-BMP J205 G/BOX BLADE MOUNT
7 DISC-315-25 DISC (315 BLADE 25 deg)
8 BLD-25025H-WSR 5xDIA 26 BLADE WASHER
9 BLDB-315-25-SY-STP1 BLADE STOP SPACER
10 BLDB-315-25-SY2SP08 8mm SPACER
11 BB25-16-26 BLADE BUSH
12 BB25-16-32 BLADE BUSH
13 1/2F 1/2" FINE NYLOC NUT
14 12x134FBZP 1/2"x1 3/4" FINE BOLT
1/2"x2 1/2" FINE SOCKET HEAD
15 12x212FSKS
12.9
16 D281421 DISC SPRING 28x14.2x1.0
17 DSW34 DISC SPRING 34x16.3 x2
18 M16 M16 NYLOC NUT
19 M16x50BZP M16x50 BOLT
20 M16x60BZP M16x60 BOLT
46
19
17
14
5
16
11
1
17
18
4
18
13
17
8
12
17
20
QTY
2
2
1
1
2
1
1
2
2
2
2
2
8
4
4
4
8
4
2
2
www.major-equipment.com

705-DCBLDHTX-R (MJ30-250/200)

6
10
9
3
7
2
15
ITEM PART NUMBER DESCRIPTION
1 BLD-25025-OVL
2 BLD-25025T-10C
3 BLDB-294-25
4 BLDBX-315-25
5 BLDBXT-315-30
6 DF-BMP
7 DISC-315-25
8 BLD-25025H-WSR
9 BLDB-315-25-SY-STP1 BLADE STOP SPACER
BLDB-315-25-
10
SY2SP08
11 BB25-16-26
12 BB25-16-32
13 1/2F
14 12x134FBZP
15 12x212FSKS
16 D281421
17 DSW34
18 M16
19 M16x50BZP
20 M16x60BZP
19
17
14
5
13
16
11
17
18
4
13
12
17
20
OVERLAP FOR BLADE
250xDia 25
Twist Blade 250xDia 25 (Clk)
BLADE BACK (294 CTR 25
deg)
CROSS BLADE BACK (315
CTR 25 deg)
OVERLAPPER MOUNT
J205 G/BOX BLADE MOUNT
DISC (315 BLADE 25 deg)
5xDIA 26 BLADE WASHER
8mm SPACER
BLADE BUSH
BLADE BUSH
1/2" FINE NYLOC NUT
1/2"x1 3/4" FINE BOLT
1/2"x2 1/2" FINE SOCKET
HEAD 12.9
DISC SPRING 28x14.2x1.0
DISC SPRING 34x16.3 x2
M16 NYLOC NUT
M16x50 BOLT
M16x60 BOLT
1
18
17
8
2
QTY
2
2
1
1
2
1
1
2
2
2
2
2
8
4
4
4
8
4
2
2
