Major Cyclone MJ30-560 Handbuch Seite 31

MJ30-350 Wing Assembly
52
40
27
14
40 34
41
49
55
22
19
53
42
43
48
43
48
MJ30-350 Wing Assembly
18 MJ30-350-GRD35 REAR RUBBER FLAP
MJ30-350-
19 WING RUBBER
GRD41H
113 PCD COUPLING
20 MJRC-23
4mm PLT
21 MJ30-350-GRD36 REAR RUBBER CLAMP
22 MJ30-350-GRD40 WING CLAMP
23 DRV-RC-SWT410 MJ70-410 DRIVE
24 MJ30-350-WA11 RAM SPACER
25 12HEX109 1/2F HEX 10.9
1/2"x1 1/2" FINE
26 12x112FSKS
SOCKET HEAD 12.9
27 15012 CAT 1 PIN DIA 19x76mm
GUARD (COVER 760/
28 190760
BASE 661)
29 1F 1" FINE NYLOC NUT
30 1x10FBZP 1"x10" FINE BOLT
31 1x5FBZP 1"x5" FINE BOLT
32 5/8F 5/8" FINE NYLOC NUT
33 58x2FBZP 5/8"x2" FINE BOLT
34 AN099/10 LINCH PIN DIA 9.5
35 CP176-181MG1 45mm INSERT
DISC SPRING 39x17x4
36 CW39174
(YELLOW)
37 FW1 DIA 1" FLAT WASHER
38 FWM12 M12 FLAT WASHER
M12 FLAT WASHER (EX-
39 FWM12XL
LARGE)
43
38
38
47
55
38
6
12
1
1
2
1
1
1
1
12
12
1
1
3
1
2
8
8
1
2
2
7
38
7
www.major-equipment.com
43
38
15
38
45
29
10
37
37
40 FWM16 M16 FLAT WASHER
41 FWM20 M20 FLAT WASHER
42 FWM8 M8 FLAT WASHER
43 M12 M12 NYLOC NUT
44 M12x20SZP M12x20 SET BOLT
M12x30 SOCKET
45 M12x30SKBH
BUTTON HEAD 10.9
46 M12x30SZP M12x30 SET BOLT
M12x35 SOCKET
47 M12x35SKBH
BUTTON HEAD 10.9
48 M12x40BZP M12x40 BOLT
49 M16 M16 NYLOC NUT
50 M16x30SZP M16x30 SET BOLT
51 M16x50BZP M16x50 BOLT
M16x55 SOCKET HEAD
52 M16x55SKZP129
12.9
53 M8 M8 NYLOC NUT
54 M8x16SZP M8x16 SET BOLT
55 M8x25BZP M8x25 BOLT
56 NL12SP M12 SP NORDLOCK
57 NL8SP M8 SP NORDLOCK
