Your door telephone
Ring tone OFF button
with status display
(red LED is on)
Light switch button
Handset
Door release button
Volume control for
ring tone and voice
Green LED is ON
incoming door-, flat-door or internal calls
active voice communication
blinks 3 times
busy voice channel,
door release can still be realised
Red LED is ON
ring tone OFF is activated,
Both LED are ON
ring tone selection is activated
flash continuously
error indication
The device is not ready for operation.
Error has to be fixed by a qualified electrician.
Handling
Green LED
Red LED
The bell rings
A ring tone signals an incoming
Light switching
call from front-door, flat-door or
Press the light switch button.
an internal call.
The green LED is ON.
Ring tone mute
Start a voice communication
Press ring tone OFF button. An
Control key
A voice communication will
incoming call will not be signal-
be established by lifting the
led acoustically.
handset.
The red LED is ON.
The green LED is ON.
To end ring tone mute press ring
The green LED blinks 3 times,
tone OFF button again.
if a voice communication
The red LED is OFF.
already exists. Door release
can still be realised.
Additional call and switching
Terminate
functions can be added to
voice communication
the door telephone.
Put the handset down or
For more information refer
automatic termination after at
to www.tcsag.de.
least 2 minutes.
Door release
Press the blue colored door
release button.
ANNOUNCEMENT
FUNCTION
This indoor station is
suitable for the transmission
of announcements.
A loud tone signals the
announcement. Please
observe that in this case,
user individual settings such
as volume resp. ring tone
mute become ineffective!
Configuration
Ring tone selection
3. Deactivate
Different ring tones can be
ring tone selection
selected for different incoming
Press the ring tone OFF button
calls (e.g. front-door calls, flat-
shortly. If no button has
door calls, internal calls). Please
been pressed for 8 seconds, the
proceed as follows:
device automatically ends the
ring tone selection.
1. Activate ring tone selection
An acknowledegement tone
Terminate voice communication.
sounds.
Press the ring tone OFF button
Both LEDs are OFF.
, hold it for 8 seconds.
An acknowledegement tone
sounds.
Adjust the volume
Both LEDs are ON.
The volume of the ring tone
The ring tone selection is
resp. of the voice can be ad-
activated.
justed in 8 steps by turning the
volume control to the right
2. Select ring tone
(louder) or to the left (lower).
a) for front-door call
Press the door release button
Ring tone volume
when
until the desired ring
handset is put down
tone sounds.
Voice volume at the door
b) for flat-door call
telephone
when the handset
Press the light switch button
is lifted and a voice communi-
until the desired ring
cation is established
tone sounds.
c) for internal call
Press the control key
lower
louder
until the desired ring tone
sounds.
The ring tone selected last
will be stored.
Link to PDF download
Reinigung
Cleaning
Reinigen Sie das Türtelefon mit
Clean the door telephone using
einem trockenen oder ange-
a dry or slightly moist cloth.
feuchteten Tuch. Stärkere Ver-
Remove stronger stains with a
schmutzungen entfernen Sie mit
mild household cleaner.
Haushalts-Kunststoffreiniger.
Vermeiden Sie das Eindringen
Avoid water entering the
von Wasser in das Gerät! Ver-
device! Do not use any
wenden Sie keine aggressiven
aggressive or abrasive
und kratzenden Reinigungs-
cleaning agents!
mittel!
Service
Service
Die Gewährleistung erfolgt
The legal regulations are
entsprechend den gesetzlichen
applicable in case of warranty.
Bestimmungen.
The replacement of the device
Der Austausch des Gerätes
in the fault case has to be
im Fehlerfall muss durch Ihren
carried out by your qualified
Elektrofachmann erfolgen.
electrician.
Entsorgung
Disposal
Die Geräte, gekenn-
The adjoining symbol
zeichnet mit neben-
shows, that the de-
stehendem Symbol,
vice has to be dispo-
sind getrennt vom
sed separately from
Hausmüll zu entsor-
domestic waste. The
gen. Die verwendeten Materi-
materials used are recycable.
alien sind recyclebar. Bitte leisten
Please do help protecting out
Sie einen Beitrag zum Schutz
environment and dispose the
unserer Umwelt und entsorgen
device via a collection point for
Sie das Gerät über eine Sammel-
electronic scrap.
stelle für Elektronikschrott.
TCS TürControlSysteme AG
hotline@tcsag.de
Geschwister-Scholl-Straße 7
39307 Genthin
Technische Änderungen vorbehalten.
Germany
Rights to technical modifications reserved.
www.tcsag.de
Art.-Nr. 0034167
Service
Version 3 A
