Safety notes

Thank you!
Thank you for purchasing the Rocco and your
confidence in us.
Indicators and controls
Fig. 1:
1 Dust chamber cover release latch
2 Suction hose release latch
3 Dust filter bag change indicator
4 Telescopic tube catch
5 Bypass vent
6 Suction control
7 Cable retraction button
8 On/Off switch
9 Exhaust filter cover release latch
10 "Carpet/hard floor" switch
(illustration serves as an example)

Accessories

Fig. 2:
1 Accessory holder
2 Upholstery nozzle
3 Furniture brush
4 Crevice nozzle
Fig. 3:
1 Floor nozzle included in scope of delivery
(illustration serves as an example)
* optional accessories (* depending on model
and scope of delivery):
2 *Parquet brush (M203): for vacuuming del-
icate surfaces (e.g. laminate, parquet)
3 *Turbo brush (M209): is used to vacuum
non-sensitive carpets, runners, mats, and
the like
Fig. 4:
1 Dust filter bag with holder (in the appliance)
2 *extra dust filter bags (in the box, optional*)

3 Operating Manual

Technical data
Type of appli- : Cylinder vacuum cleaner
ance with bag
: Rocco [M7023 (-0/.../-9)]
Model
Voltage : 220 V – 240 V~, 50/60 Hz
Power : 1,200 W nom. – 2,000 W max.
Dust filter bag : approx 2.8 litres
Filters : Motor protection filter,
exhaust filter
Length of : approx. 5 m
power cord
Weight : approx. 4.8 kg
Technical and design specifications may be changed
in the course of continuous product improvement.
© Royal Appliance International GmbH
Swirl , MicroPor and "Y101" are registered trade
marks of a company of the Melitta group and used
with their permission.
8
1 Safety notes
1.1 Re: Operating Manual
Read this operating manual carefully before
using the appliance.
Safekeep this operating manual carefully. In-
clude the operating manual if you pass the ap-
pliance on to third parties.
Violations of the operating instructions can
lead to severe injuries as well as damages
to the appliance.
We take no responsibility for damages due to
violations of these operating instructions.
Notices for your safety are especially marked.
Always observe these notices to avoid acci-
dents and damages to the appliance:
WARNING:
Warning concerning health hazards describ-
ing possible risks of injury.
ATTENTION:
Calls attention to possible hazards to the
appliance or other objects.
NOTE:
Highlights tips and information for you.
1.2 Re: Children
This appliance can be used by children
aged from 8 years and above and persons with
reduced physical, sensory or mental capabili-
ties or lack of experience and knowledge if they
have been given supervision or instruction con-
cerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
Keep the appliance and its cord out of
reach of children less than 8 years when it is
switched on or cooling down.
Packing material must not be used to play
with. There is danger of suffocation.

1.3 Re: Appropriate Use

The cylinder vacuum cleaner may only be
used in households. It is not suitable for com-
mercial use.
Use the cylinder vacuum cleaner only for
cleaning dry, normally soiled floors, rugs and
curtains.
Any other use is considered inappropriate
and is prohibited.
It is specially forbidden to:
Vacuum-clean:
- Persons, animals, plants, especially hair,
fingers and other parts of the body as well
as pieces of clothing worn on the body.
They could be sucked in and cause inju-
ries.
- Water and other liquids, especially mois-
ture from carpet-cleaning agents. Mois-
ture inside the appliance can lead to
short-circuiting.
- toner dust (for laser printers, copying ma-
chines, etc.). There is danger of fire or ex-
plosion.
- hot ash, burning cigarettes or matches.
This could cause a fire.
- pointed objects such as glass fragments,
nails, etc. These objects destroy the filter.
- Rubble, plaster, cement, fine drilling-
dust, make-up, etc. These might damage
the appliance.
The use of the appliance near inflammable
or explosive materials. There is danger of fire
or explosion.
Outdoor use. There is danger of rain and
dirt destroying the appliance.
Sticking objects into the appliance's open-
ings. It could overheat.
Attempting to perform repairs yourself.

1.4 Re: Power supply

The appliance runs on electricity, that
means there is always danger of electric shock.
So please especially observe the following:
- Never touch the plug with wet hands.
- Always pull directly at the plug if you want
to disconnect the appliance from the
mains. Never pull the power cord, it might
break.
- Take care that the power cord is not bent,
pinched, rolled over or gets in contact
with heat sources.
- Use only extension cords suited to the
power requirements of the appliance.
- Never immerse the appliance in water or
other liquids.
- Only operate the appliance if your mains
voltage is the same as that indicated on
the appliance's nameplate. Wrong volt-
age can destroy the appliance.

1.5 If the appliance is defective

Never use a defective appliance or operate
an appliance with a defective power cord. If the
power cord of this appliance is damaged it
must be replaced by the manufacturers, their
authorised service representative or a similarly
qualified person to avoid danger to the user.
Refer a defective appliance to an author-
ised dealer or the Royal Appliance service for
repair. Address: page 32, „International Ser-
vice".
