Extension Operation
Extension operation is possible in conjunction with FM
Sensors by activating via an NC pushbutton in the voltage
supply line.
Extension Operation via NC Pushbutton (see Fig. 1)
in conjunction with FM Sensors 6810-21x-101:
The function activated via the NC pushbutton causes the
devices to be switched on for approx. 80 seconds.
This reaction is independent of the lighting conditions at
the installation site.
in conjunction with FM Sensors 6800-xxx-10x(M) and
Busch Watchdog
The function activated via the NC pushbutton causes the
devices to be switched on for the time set on the FM
Sensor (at least 1 minute with time settings of < 1 minute).
This reaction is independent of the lighting conditions at
the installation site.
NOTE
The only exception in this regard is the short-time im-
pulse .
®
‚ Präsenz 6813-xxx:
