Technische Daten:

HEATKILLER® CPU Rev3.0
2
HEATKILLER® CPU Rev3.0 LT
HEATKILLER® CPU Rev3.0 LC
Abmaße (L x B x H)
60 x 59 x 17 mm
(Cu/Ni-Bl) 390g
Gewicht
(LT/LC) 140g
Material
(Cu/Ni-Bl) Kupfer / Kupfer
(Boden/Deckel)
(LT/LC) Kupfer / POM
Material (Halterung)
Edelstahl
Anschlüsse
G ¼ Zoll
(Cu/Ni-Bl) 95°C
Temperaturfest bis
(LT/LC) 80°C
AMD Sockel
754, 939, 940, AM2, AM2+,
AM3, AM3 +
Kompatibel zu
Intel Sockel
775, 1150, 1155, 1156, 1366,
2011

1. Montage auf den Sockeln

775 / 1155 / 1156 / 1150 / 1366
Im
Laufe
die
Erstinstallation
Mainboard
ausgebaut
nachfolgenden CPU -Wechsel ist ein weiterer
Ausbau nicht mehr erforderlich. Vor der
Installation des HEATKILLER CPU-Kühlers ist
der
Prozessor
gleichmäßig
Wärmeleitpaste zu versehen. Die Montage
erfolgt analog zur untenstehenden Abbildung,
dabei ist zu beachten, dass die mitgelieferten
Unterlegscheiben nicht vergessen werden.
Nach der Befestigung der vier Abstandshalter
können diese mit einem Ringschlüssel (Größe
7) angezogen werden. Die Schrauben (M4x25)
werden nun mit einer Druckfeder versehen
muss
das
werden,
für
mit
einer

Technical data:

HEATKILLER® CPU Rev3.0
HEATKILLER® CPU Rev3.0 LT
HEATKILLER® CPU Rev3.0 LC
Dimensions (L/W/H)
60 x 59 x 17 mm
(Cu/Ni-Bl) 390g
Weight
(LT/LC) 140g
(Cu/Ni-Bl) copper / copper
Material (bottom/top)
(LT/LC) copper / POM
Material (fastener)
Stainless steel
Connections
G ¼ Inch
Temperature-
(Cu/Ni-Bl) 95°C
resistant up to
(LT/LC) 80°C
AMD sockets
754, 939, 940, AM2, AM2+,
AM3, AM3 +
Compatible with
Intel sockets
775, 1150, 1155, 1156, 1366,
2011
1. Mounting on sockets
775 / 1155 / 1156 / 1150 / 1366
The motherboard must be removed for the
initial
assembly.
For
modifications further removal is not necessary.
Before installing the HEATKILLER CPU cooler
the processor is to be evenly applied with a
thermal industrial paste. The assembly is as
shown in the figure below. It is important to
use the supplied washers. After the four
spacers are mounted these can be tightened
with a key ring (size 7). The (M4x25) screws
are now to be fitted with a pressure spring and
screwed into the spacers. All four screws are
to be evenly (crosswise) screwed in without
force. For further details on the screw-in depth
subsequent
CPU
