Inhaltszusammenfassung für Watercool HEATKILLER LGA 1700
Seite 1
PDF-file in the service area of our Format finden Sie im Servicebereich unserer homepage. www.watercool.de Homepage unter www.watercool.de Installation is at your own risk. Watercool Die Installation erfolgt auf eigene Gefahr. accepts no liability for any damages caused to Das Nichtbeachten der Montageanleitung kann hardware and data.
Technische Daten / Technical Data Abmaße / Dimensions (L x B x H) 87 x 87 x 7 mm Gewicht / Weight 103g Material Aluminium eloxiert / aluminum anodized 4x UNC 6-32 - ILM Montage (ILM mounting) Gewinde / Threads 4x M4 –...
3. Disassembly of the ILM 3. Demontage des ILM Start by laying the motherboard flat and Beginnen sie damit das Mainboard flach unfolding the socket's ILM (Independant hinzulegen Sockel Loading Mechanism). We recommend inserting aufzuklappen. Wir empfehlen das Einlegen a processor (for LGA1700) to protect the pins einer Prozessors ( für LGA1700 ) um die Pins of the socket.
4. Montage der Heavy Backplate 4. Mounting the Heavy Backplate ohne Washer-Mod without washer mod Place the HEATKILLER® LGA 1700 HEAVY Platzieren Sie die HEATKILLER® LGA 1700 BACKPLATE on the back of the motherboard HEAVY BACKPLATE auf der Mainboard (see illustration and pay attention to the Rückseite (Siehe Abbildung und achten sie auf rotational alignment of the backplate ).
5. Montage der Heavy Backplate mit 5. Mounting the Heavy Backplate with washer mod Washer-Mod Place the HEATKILLER® LGA 1700 HEAVY Platzieren Sie die HEATKILLER® LGA 1700 BACKPLATE on the back of the motherboard HEAVY BACKPLATE auf der Mainboard (see illustration and pay attention to the Rückseite (Siehe Abbildung und achten sie auf rotational alignment of the backplate ) and die Ausrichtung der Backplate) und legen sie...
Seite 6
Washer Mod Washer Mod Der Washer Mod verringert die Anpresskraft The Washer Mod reduces the contact pressure des ILM auf die CPU. Der Heatspreader wird of the ILM on the CPU. The heatspreader is dadurch deutlich weniger verformt. Diese therefore deformed significantly less. This Modifikation wird von uns empfohlen.
