RUSTA 626701450101 Gebrauchsanweisung Seite 22

Fig 2
Drill three 5cm deep holes in the size as the following picture shows. Ref. Fig. 3.
Step 3:
NO
Drill three 5cm deep holes in the size as the following picture shows. Ref. Fig. 3.
Drill tre stk. 5 cm dype hull av den størrelsen som det følgende bildet viser.
3
Fig. 3 8mm masonry drill / Cross section of wall/ceiling
8mm slagbor.
Step 4:
Fig. 3 8mm masonry drill / Cross section of wall/ceiling
Insert one 8x45mm plastic expansion tube in each of holes. Ref. Fig. 4.
Sett inn et 8x45 mm plastplugg i hvert hull.
4
Step 4:
Insert one 8x45mm plastic expansion tube in each of holes. Ref. Fig. 4.
Fest braketten med ST4.8x50 krysskruer og underlagsskiver.
5
B
Sett vertikalmarkisen på braketten.
6
Sørg for at markisen låses inn i braketten.
22
D
E
C
Tverrsnitt av vegg / tak
Cross section
of ground
5 cm
Fig. 4
Fig. 4
B
A
