ENG

PACKAGE CONTENT

A
Top pole
B
Bottom pole
C
Side frame
D
Side frame
E
Side frame
F
Side frame
G
Side frame
H Roof pole center
I
Roof pole center
J Roof pole corner
K
Roof pole corner
L Top connector center
M
Roof cover extender
N Wall support
O Wall support peg
P
Wall support peg
Q Wall support bracket
R
Wall support bracket
S Top connector corner
T
Bracket
U Ground pegs
V
Screw M6x15 mm
W Screw M6x20mm
X Roof cover 3x4m
2#
Bolt M5x15mm
3#
Djustable spanner
4
Antal
x 4
x 4
x 4
x 2
x 4
x 2
x 2
x 4
x 4
x 4
x 4
x 1
x 4
x 4
x 8
x 8
x 4
x 4
x 2
x 4
x 8
x 32
x 8
x 1
x 16
x 1
