6.2.1 Extremly dirty records
If the records are extremely dirty, it may be necessary to extend the cleaning process.
In order to extend the cleaning time, keep the start button (1 ) pressed until a signal can be heard.
There are several signals if the button is pressed for longer. Each signal extends the cleaning time
by one minute. It is possible to extend the time by a maximum of five minutes (five signals).
6.2.2 Repeat the drying process
The drying process can be repeated in case water drops are still left on the record after the cleaning process.
1. Keep the start button (1 ) pressed down. 3
- The drying process starts automatically after six signals.
- Make sure you do not touch the wet cleaning barrels while taking out the record.
This requires a little skill and experience.
NOTE !
!
Make sure you keep the start button (1 ) pressed down until the drying process starts.
Otherwise the cleaning process (including the washing) will be restarted.
6.2.3 Inserting the record
Inserting the record properly helps to ensure good cleaning results without damaging the record.
1. Insert the record vertically into the slot. Make sure that the record is inserted into the designated
retainer (picture 6.1). Then turn the record to the left with gentle pressure so that the driving
rings can grip and the record can be transported safely.
Picture 6.1
CAUTION !
!
If a record is inserted wrong, the record might get damaged.
If the record is not transported, turn off the machine immediately and insert the record
properly. Then restart the machine.
No liability is assumed for damages. These damages are detectable by microscope.
9 Cleaning the device
CAUTION !
Pull out the mains plug from the power socket before cleaning the device.
The device must not be put in water.
Cleaning the outside surfaces
- The outside surfaces can be cleaned with a damp cloth. Use a mild household detergent or
cockpit spray to remove more severe dirt.
Cleaning the water tank
- When the cleaning liquid is changed or the device emptied completely because it is not in
use anymore, slightly tilt the device before draining the cleaning liquid, so that dirt particles
are flushed out. Then drain off the cleaning liquid. Repeat this several times during draining
until the water tank is completely empty.
Cleaning the rinsing chamber
- After use and drying the rinsing chamber can be blown out with air.
10 Changing the cleaning barrels
The four microfiber cleaning barrels last a long time, but they should be replaced after approx.
500 cleaning cycles. This reduces the risk of the records being scratched by residue on the barrels.
If the device is not used for several weeks, the microfiber cleaning barrels should be checked to see
if they have gone hard, and replaced if necessary in order to avoid damage to the record.
Fixture for the cleaning barrels
3
3
V 1.1/2017 Page 9 of 14
1. Pull the cleaning barrels off upwards
2. Put new barrels on the shaft (2) and
push them down carefully.
3. Rotate the barrels and press them down
slightly until the drive pins (1) slide into the
corresponding holes in the barrels.
2
4. Press the barrels down all the way to the
end stop.
1
V 1.1/2017 Page 11 of 14
7 Cleaning liquid
CAUTION !
Keep the concentrated cleaning liquid away from children.
The cleaning liquid must not remain in the device for more than 4 weeks.
The cleaning liquid consists of distilled or demineralized water and concentrated cleaning liquid.
The liquids are mixed together inside the water tank.
- Distilled or demineralized water can be purchased in shops.
- The concentrated cleaning liquid can be purchased from the manufacturer.
8 Changing the cleaning liquid
CAUTION !
Never allow children to change or refill the cleaning liquid.
Pull out the mains plug of the power supply unit from the power socket before changing the liquid.
Wipe up any leaked fluid immediately.
Approx. 100 records can be cleaned with one bottle of concentrated cleaning liquid,
depending on the amount of dirt.
8.1

Emptying the device

1. Place the device above a suitable bowl or sink.
- The collection bowl must be able to hold at least 4.5 liters of liquid.
2. Open the drain plug (8).
- Do not empty the cleaning liquid completely. Close the drain plug again. Slightly swing the
device back and forth to float existing particles. Then empty the device completely.
- In order to empty the device completely, tip the device slightly backwards and to the side.
3. Screw the drain plug back in again and tighten it.
8.2

Filling the device

For each filling operation, the following are required:
- 4.5 liters of distilled or demineralized water
- 1 bottle of concentrated cleaning liquid
NOTE !
!
Only use the original cleaning liquid! Other cleaning agents may cause
malfunctions or irreparable damages to the device (e.g. due to excessive
foaming, attacking the water level window) or damage the record. The
original concentrated cleaning liquid also prevents the record from becoming
electrostatically charged. No liability is assumed for damage to the device or
records if this warning is disregarded. Furthermore, the warranty will be thereby
invalidated.
1. Fill the clean cleaning liquid into the rinsing chamber (6).
- The cleaning barrels do not have to be removed.
- The float must reach the upper edge of the level indicator (3).
Due to evaporation, the filling level may become insufficient to start the cleaning process
(LED (13) lights up red). Top up with some distilled or demineralized water.
11 Cleaning the wet filter
CAUTION !
If the wet filter is not pushed all the way down, cleaning liquid may leak out of the device
while it is operating
The cleaning liquid is constantly filtered during operation.
Depending on the amount of dirt, the filter will need to be cleaned or replaced from time to time.
Inspection interval: after approx. 100 cleaning cycles
Wet filter
12 Changing the water wipers
CAUTION !
Unplug the mains plug from the power socket before changing the water wipers.
Always be careful when you reach inside the device to avoid abrasions or injuries.
The lips of the wipers may tear if the pressure is too great.
Check if the wipers are still working properly after approx. 500 cleaning cycles.
If water drops are still left on the record, or the record is no longer dried properly,
the wipers must be changed.
V 1.1/2017 Page 10 of 14
1. Remove the cover.
2. Pull out the wet filter (1) upwards.
3. Clean the filter with distilled or
demineralized water.
4. Reinsert the cleaned or new filter.
1
5. Put the cover back on.
1. Remove the microfiber cleaning barrels
(see section 10).
2. Push out the wiper (1) carefully to the left
1
while holding it with both hands.
3. Insert the new wiper in reverse order.
4. Put the microfiber cleaning barrels back on.
