4 Safety instructions
This section provides an overview of all the important safety precautions for the ideal
protection of persons and safe and reliable operation of the device.

4.1 Product safety

This device complies with all state-of-the-art and recognized safety standards.
Nevertheless potential hazards still remain.
WARNING !
- Before operating the device, check if the operating voltage indicated on the label
corresponds to the local mains voltage.
- Do not use the device if the mains plug, mains cable or power supply unit or the
device itself are damaged or the device has been dropped or water is leaking out of it.
- If the power supply unit, mains cable or the device itself are damaged, it may only be
repaired or replaced by the manufacturer.
- Do not leave the device unattended as long as it is connected to the mains supply.
- This device may be used by children over 8 years old and by persons with limited
physical, sensory or mental abilities or persons with no previous experience,
provided that they have been instructed thoroughly how to safely use the device
and appropriate supervision is guaranteed.
Adequate instructions about the risks involved when using the device are essential.
- Do not allow children to play with the device.
- Keep it away from children under the age of 8 years while it is switched on.
CAUTION !
- Only connect the device to an earthed power socket.
- Always use the device on a level and stable surface.
- Check the mains cable regularly for possible damages.
- Disconnect the mains plug from the power source
- while refilling or emptying the water tank
- while cleaning the device
- if you stop using the device.
-The device is solely intended for indoor use.
Before transporting the device, the cleaning liquid mus be emptied out.
4.2 Disposal
Help to prevent valuable recources and contribute to the protection of the environment.
- Do not dispose of the device in the normal domestic refuse at the end of it´s life cycle.
Return it to your dealer or to an official collection point for recycling.
- The packaging is made of eco-friendly material and is thus recyclable.

5.1 Description of Functions

The records are automatically cleaned and dried when the device is started.
The cleaning liquid is dispensed on the record in order to clean it. Dirt particles are
dissolved by ultrasound and removed from the record by four rotating microfiber rollers.
A filter prevents the dirt particles from flowing back into the circulating cleaning liquid. After
the cleaning process, the record is dried by two high-performance ventilators..

5.2 Scope of delivery

Description Quantity
Vinyl Cleaner PRO 1
Power supply unit 1
Concentrated cleaning liquid 2
Dust cover 1
Cover for wet filter 1
1
V 1.1/2017 Page 5 of 14
V 1.1/2017 Page 7 of 14
5 Product overview
Front
2
3
1. Operating panel
2. Ventilator for drying
3. Level indicator
4. Spirit level
5. Water wiper
Operating panel
16
15
14
11
ON
13
OFF
12
6 Operation
CAUTION !
During normal use, no liquid may leak out of the device. In case of a fault, disconnect
the mains plug and contact the manufacturer.
All position details refer to the position numbers in the section `Product Overview´
6.1 Preparation
1. Place VINYL CLEANER PRO on a level surface.
- Check using the spirit level (5).
- The air bubble must be roughly in the middle of the circular mark.
2. Check the filling level of the cleaning liquid.
- The float must be aligned with the upper edge of the level indicator
- Refill with cleaning liquid when necessary (see section "Changing cleaning liquid ). "
- he green LED (1 ) lights up when the level is sufficiently high T 5
and the red LED (1 ) stops lighting up. 4
3. Check the wet filter (7).
- The wet filter must be inserted completely into the slot.
- The cover must be fitted on properly.
4. Connect to the power supply.
- Connect the round jack plug (24 V) of the power supply unit (10) to the socket (9).
- Connect the power supply plug (230 V) to the earthed power socket.
5. Turn on the main switch (1 ). 2
- The LED (1 ) above the main switch must light up yellow. 1
- If the filling level is sufficient, the LED (1 ) lights up green. If the LED (1 ) blinks red,
recheck the filling level.
The device is now ready for use.
6.2 Cleaning a record
CAUTION !
Make sure the record is rotating after the cleaning process has been started.
Only a rotating record guarantees a normal cleaning process and prevents damages
of the record. No liability is assumed for damage if this warning is disregarded
1. Repeat steps as described in section 6.1 "Preparation".
2. Insert the record into the device from above and press down until a slight resistance can be felt.
3. Turn the record counterclockwise until the wiper lips (4) fold upwards and you feel the record
slipping noticeably between the driving rings.
4. Press the start button (1 ). 3
- An acoustic signal can be heard.
- The LED (1 ) lights up yellow. 6
5. There is an acoustic signal following the completion of the cleaning process and the LED (1 ) 5
lights up green.
6. Take out the cleaned and dried record.
Back
4
5 6
10
9
8
6. Rinsing chamber with cleaning barrels
7. Wet filter
8. Drain plug for cleaning liquid
9. Connection for power supply unit
10. Power supply unit
11. The LED light is yellow when the device is on.
12. Main switch
13. Start button
14. The LED light is red if there is not enough
liquid inside the device.
15. The LED light is green when the cleaning process
is finished and the device is ready to be used.
16. The LED is yellow during the cleaning process.
V 1.1/2017 Page 6 of 14
(3) .
5 4
.
