8. Repeat the steps 1 to 6 for any further satellites/transponders, if applicable.
 Select Recalculation and press OK to discard any previous settings and to
again determine antenna position.
 Press EXIT to return to the submenu Antenna Setup.
 Select Limit setup and press OK to
open the window Limit setup.
1. Select Limit setup to switch between Disable Limit, West Limit and East Limit.
2. Mark the button Limit setup and move the limit - as defined in the previous
step - to the east or west by using the keys /
3. Mark the button Go to Reference and then press OK to move the motor an-
tenna to its starting position.
4. Press EXIT to return to the submenu Antenna Setup.
7.2.3.2.2 USALS
A satellite position is defined as reference, and the data provided for latitude and
longitude are then used together with such basic values to calculate the rotary
movement for all remaining satellites.
 Select Local Longitude to enter the longitude of the position of your antenna by
using the numeric keys of your remote control.
 Select Local Latitude to enter the latitude of the position of your antenna by
using the numeric keys of your remote control.
 Select Motor Setting and press OK
to open the submenu Motor Set-
ting.
1. Select Satellite to select the satellite that should be used as reference for US-
ALS control of the antenna.
2. Select Transponder to select the transponder that should be decisive for the
antenna position (usually the transponder that is used to send your preferred
channel).
AVANIT SHD5
Extended Settings and Functions
and / .
