HOW TO ASSEMBLE THE
INDOOR CYCLE
1X
SW 17/19MM
SW 13/15MM
1.
PLEASE ASSURE THAT NUTS ARE TIGHTENED WITH
SIGNIFICANT FORCE TO MINIMIZE LOOSENING.
DURING USE.
3.
STOP MARK
SEAT CLAMP MUST BE TIGHTENED SECURELY FROM
BOTH SIDES TO MINIMIZE LOOSENING DURING USE.
'
1X
15MM
WRENCH
3MM
6MM
2.
A
PLEASE ASSURE THAT NUTS ARE TIGHTENED WITH
SIGNIFICANT FORCE TO MINIMIZE LOOSENING.
DURING USE.
4.
STOP MARK
SEAT CLAMP MUST BE TIGHTENED SECURELY FROM
BOTH SIDES TO MINIMIZE LOOSENING DURING USE.
HAND
TIGHT
A (1 : 2)
5
