4. Safety Regulations

The use of the intrinsically safe Ex-Penlight meets the requirements of
the regulations providing that the user observes and applies the
requirements as laid down in the regulations and that improper and incor-
rect use of the unit is avoided.
- The device must not be opened within the hazardous area.
- Batteries (see page 17) must only be changed outside the hazardous
area.
- The bulb must only be changed outside the hazardous area.
5. Data & Specification
Operating temperature
CE number
IP Protection Level
Certificate of Conformity
Certification
Authorised for Device group II, Category 2 gas group C potentially
explosive gases, vapours or mist, Temperature class T4.

6. Operation

Pressing the plunger switch on the top of the torch switches the light on
and off.
7. Replacement of Defective Bulbs & Batteries
Remove the lens head by unscrewing in an anti-clockwise direction.
Remove defective bulb – ensuring that only Philips type 222 is used as
replacement.
The use of any other type of bulb is strictly forbidden in that it will
invalidate the Ex-data certification. When replacing the batteries please
take care to ensure that the positive poles of the batteries point towards
the light bulb/lens head. Replace the lens head. Only batteries LR03
according to IEC (see tables) may be replaced. The use of any other type
of battery is strictly forbidden in that it will invalidate the EX-data
certification.
: -20°C ... +40°C
:
0102
: IP 54
: TÜV 99 ATEX 1512
: II 2 G EEx e ia IIC T4
7
