Baumer OM70 Bedienungsanleitung Seite 53

Laser Klasse 1
Laser Punkt
Fokus dist. 130 mm
Fremdlichtsicherheit < 170 kLux
Arbeitstemperatur -10 ... +50 °C
Lagertemperatur -20 ... +60 °C
Aufwärmzeit 20 min.
Schutzart IP 67
Vibrationsfestigkeit (sinusförmig) IEC 60068-2-6:2008
± 0.75mm p-p for f = 10 - 58Hz , 10 cycles for each
axis 10g for f = 58 -2,000Hz, 10 cycles for each axis
Vibrationsfestigkeit (Zufall) IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 – 1,000Hz, 300 minutes /
axis (>10.6g RMS)
Schockfestigkeit IEC 60068-2-27:2009
50g / 11ms and 100g / 6ms, 10 shocks in each axis
and each direction
Stossfestigkeit IEC 60068-2-27
100g / 2ms, 5,000 shocks in each axis and each
direction
11200065
Optische Eigenschaften
Laser Klasse 1
Laser Punkt
Fokus dist. 130 mm
Lichtquelle
AlGaInP laser diode
Wellenlänge 660 nm
Betriebsmodus pulsed
Pulsdauer 4 µs...2.5 ms
Pulsperiode 0.4...6 ms
Emittierte Gesamtpulsleistung 0.65 mW
Strahlform Point laser
Empfänger-Position L1 38 mm
L2 55 mm
Fokusabstand df 130 mm
Laserpunkt Grösse
@Anfang Messbereich tbd
@Mitte Messbereich tbd
@Ende Messbereich tbd
Nominal ocular hazard distance N/A
(NOHD)1
Laserklassifizierung (per IEC Laser class 1
1
Ausserhalb der "Nominal ocular hazard distance" ist die Strahlenbelastung unter dem Grenzwert der Laserklasse 1
de_BA_OM70_point_line.docx
06.06.2018 08:27/tof V2.0 ANW_81250853
Laser Klasse 1 Laser Klasse 1
Laser Linie Laser Punkt
Fokus dist. 130 mm Fokus dist. 180 mm
< 170 kLux
-10 ... +50 °C
-20 ... +60 °C
20 min.
IP 67
IEC 60068-2-6:2008
± 0.75mm p-p for f = 10 - 58Hz , 10 cycles for each
axis 10g for f = 58 -2,000Hz, 10 cycles for each axis
IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 – 1,000Hz, 300 minutes /
axis (>10.6g RMS)
IEC 60068-2-27:2009
50g / 11ms and 100g / 6ms, 10 shocks in each axis
and each direction
IEC 60068-2-27
100g / 2ms, 5,000 shocks in each axis and each
direction
11200066 11200067
Laser Klasse 1 Laser Klasse 1
Laser Linie Laser Punkt
Fokus dist. 130 mm Fokus dist. 180 mm
AlGaInP laser diode
660 nm
pulsed
4 µs...2.5 ms 4 µs...2.5 ms
0.4...6 ms 0.4...6 ms
0.65 mW 0.65 mW
Short line Point laser
38 mm
55 mm
130 mm 180 mm
tbd tbd
tbd tbd
tbd tbd
N/A N/A
Laser class 1
53/68
Laser Klasse 1 Laser Klasse 1
Laser Linie Laser Punkt
Fokus dist. 180 mm Fokus dist. 240 mm
< 170 kLux
-10 ... +50 °C
-20 ... +60 °C
20 min.
IP 67
IEC 60068-2-6:2008
± 0.75mm p-p for f = 10 - 58Hz , 10 cycles for each
axis 10g for f = 58 -2,000Hz, 10 cycles for each axis
IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 – 1,000Hz, 300 minutes /
axis (>10.6g RMS)
IEC 60068-2-27:2009
50g / 11ms and 100g / 6ms, 10 shocks in each axis
and each direction
IEC 60068-2-27
100g / 2ms, 5,000 shocks in each axis and each
direction
11200068 11112060
Laser Klasse 1 Laser Klasse 1
Laser Linie Laser Punkt
Fokus dist. 180 mm Fokus dist. 240 mm
AlGaInP laser diode
660 nm
pulsed
4 µs...2.5 ms 4 µs...2.5 ms
0.4...6 ms 0.4...6 ms
0.65 mW 0.65 mW
Short line Point laser
38 mm
55 mm
180 mm 240 mm
tbd tbd
tbd tbd
tbd tbd
N/A N/A
Laser class 1
Baumer Electric AG
Frauenfeld, Switzerland
Laser Klasse 1
Laser Linie
Fokus dist. 240 mm
11200061
Laser Klasse 1
Laser Linie
Fokus dist. 240 mm
4 µs...2.5 ms
0.4...9 ms
0.95 mW
Short line
240 mm
tbd
tbd
tbd
N/A
