Anleitung_760193.book Seite 19 Dienstag, 15. Oktober 2002 1:22 13
- Timer mode
(The timer mode corresponds to the stair-
case automatic function)
Switch on (e.g. staircase automatic func-
tion) by pressing the top of the rocker.
Switch off (e.g. staircase automatic func-
tion) by pressing the bottom of the rocker.
Note
The red LED (status indicator) is on as
while the actuator is enabled.
- Scene
The Easy push-button 4-fold can be load-
ed with 2 different scenes (A and B) per
rocker:
Beispiel Szenenbelegung:
Fig. B:
➊
A
Scenen no. 3
➊
B
Scenen no. 6
➋
A
Scenen no. 1
➋
B
Scenen no. 4
➌
A
Scenen no. 2
➌
B
Scenen no. 5
➍
A
Scenen no. 7
➍
B
Scenen no. 8
Anleitung_760193.book Seite 20 Dienstag, 15. Oktober 2002 1:22 13
Note
Up to 8 different scenes can be created
on the base unit. The Easy push-button
4-fold can be loaded with all 8 scenes.
Scene modules may be stored in the
base unit or in an external device.
Load a new scene from the base unit or a
scene module by pressing the correspond-
ing pushbutton for longer (> 3 s).
Call up a scene by briefly (< 0.8 s) pressing
the corresponding push-button.
- Priority control
The "priority control" function is a safety
function. It locks the switching function
and the timer mode in the relevant actuator
until it is deactivated again, e.g. for con-
stant light in the staircase.
Priority on/off:
Deactivate priority:
19
20
Rocker top
Rocker bottom
Anleitung_760193.book Seite 21 Dienstag, 15. Oktober 2002 1:22 13
Installation
Note
The ambient temperature should be
observed, see technical data.
Electrical connection
Connection example:
Fig. C:
Installationsvorschlag:
Bild D:
➊
Connect the red bus wire to the red
terminal (+) and the black one to the
dark grey terminal (-).
➋
The screen and the stability wire as
well as the white and yellow wires of
the bus line are not required. Insulate
and put in flush-mounted box.
➌
Wall box, DIN 49 073, Form B,
ø 60 mm
Note
Follow the assembly proposal on the
following page.
21
