Installation proposal:
Fig. E:
➊
Wall box, DIN 49 073, Form B,
ø 60 mm
➋
Supporting frame
➌
Frame
➍
Easy push-button insert 4-fold
➎
Rockers for push-button insert 4-fold
Art. no. 6213 ..
➋
Screw the supporting frame
onto the
➊
wall box
using the enclosed screws
Connect the Easy push-button insert 4-
➍
fold
as shown in the connection exam-
ple and, together with the frame
➋
into the supporting fame
.
➎
Attach the rocker
to the Easy push-but-
ton insert 4-fold.
Note
The push-button surface can be la-
belled by inscribing the rockers and
with the accompanying insertable sym-
bols.
22
Anleitung_760193.book Seite 23 Dienstag, 15. Oktober 2002 1:22 13
Bus line:
In order to avoid loops (over-voltage), the
bus line should be laid without a gap to the
power line. The minimum gap between the
insulated wire of the bus line and the insu-
lated wire of the power line is 4 mm.
Fig. F:
Note
Further information on laying the bus
line can be found in the "base unit" op-
➏
.
erating instructions and in the ZVEI/
ZVEH "Building management system,
Basic principles" handbook.
➌
, snap it
Anleitung_760193.book Seite 24 Dienstag, 15. Oktober 2002 1:22 13
Start-up with the Easy base unit
After wiring the device, switch on the bus
voltage.
Automatic recognition:
Choose the menu option "New function" or
"Edit function" in the Easy base unit.
The device is automatically recognised by
the base unit and displayed in the channel
list with the allocated device number.
Manual recognition:
If the device is no longer in the delivery sta-
tus, you should press the programming
key briefly (< 2 seconds) for recognition.
The red LED (on the back) lights up during
the recognition process.
The device is recognised by the base unit
and displayed in the channel list with the
allocated device number.
