Start-up:
If the device has been recognised, the
channel of the device appears in the chan-
nel overview of the Easy base unit.
The top or bottom of the rocker can be
pressed in order to connect (select) the
push-button channel. The channel of the
device is highlighted in the channel over-
view.
Further information can be found in the op-
erating instructions for the Easy base unit
or in the relevant documents for other ex-
ternal EIB Easy setting devices.
Behaviour when bus voltage is estab-
lished/returns
The push-button is ready for use 17 s after
the bus voltage has returned.
Behaviour when bus voltage fails
No reaction.
Anleitung_760193.book Seite 26 Dienstag, 15. Oktober 2002 1:22 13
Adjustable parameters
(adjustable on base unit)
Functions
1)
none
Switching
Dimming
Blind
Scene A and B
(for Scene function)
1)
1
2
3
4
Status when priority control is active
(for priority control function)
1)
disabled
enabled
1)
Factory setting
25
26
Timer mode
Scene
Priority control
5
6
7
8
Anleitung_760193.book Seite 27 Dienstag, 15. Oktober 2002 1:22 13
Technical data
Bus supply:
24 V / I ca. 5 mA
Ambient temperature:
Operation:
-5 °C to +45 °C
Storage:
-25 °C to+55 °C
Transport:
-25 °C to +70 °C
The device is designed for
use at a height of up to
2000 m above sea level
(MSL).
Control elements:
4 Rockers
Programming key, manual,
on the back of the device.
Display elements:
1 green LED:
Operation indicator
4 red LED's:
Status indicator
1 red LED (back):
Programming control
Connection:
Bus supply terminal via two
1 mm pins
Device width:
Suitable for a size 60 flush-
mounted box
EC Directives:
Complies with low voltage
directive 73/23/EEC
Complies with EMC direc-
tive 89/336/EEC
