Important advice
The Easy push-button insert 4-fold can
only be used in conjunction with the EIB
Easy base unit (Article no. 7900 29) or an-
other external EIB Easy setting device.
The Easy push-button insert 4-fold re-
quires a bus line. Information on laying the
bus line can be found in the "base unit" op-
erating instructions and in the ZVEI/ZVEH
"Building management system, Basic prin-
ciples" handbook.
The relevant norms, guidelines, rules and
regulations of each country apply. Any
work on the installation bus must only be
carried out by qualified electricians. The
device should be protected against mois-
ture, dirt and damage during transporta-
tion, storage and operation. Do not operate
the device beyond the specified technical
data.
16
Anleitung_760193.book Seite 17 Dienstag, 15. Oktober 2002 1:22 13
Function
The Easy push-button insert 4-fold has the
following functions, the settings for which
are made on the base unit:
- Switching
Switch on by pressing top of rocker.
Switch off by pressing bottom of rocker.
Note
The red LED (status indicator) is on
while the actuator is enabled.
- Dimming
Switch on by briefly (< 0.8 s) pressing the
top of the rocker.
Switch off by briefly (< 0.8 s) pressing the
bottom of the rocker.
Increase light by pressing the top of the
rocker for longer (> 0.8 s).
Decrease light by pressing the bottom of
the rocker for longer (> 0.8 s).
Note
The red LED (status indicator) is on
while the actuator is enabled.
Anleitung_760193.book Seite 18 Dienstag, 15. Oktober 2002 1:22 13
- Blind
Open blind by pressing the top of the rock-
er for longer (> 0.8 s).
By briefly pressing the top of the rocker (<
0.8 s), the blind stops opening, or the slats
are opened one by one.
Close blind by pressing the bottom of the
rocker for longer (> 0.8 s).
By briefly pressing the bottom of the rocker
(< 0.8 s), the blind stops closing, or the
slats are closed one by one.
17
