General

Saftey
The Public Display is used to visualize and present output data and measured values for

Device design

a photovoltaic system. This large-scale display allows you to monitor the output data,
while at the same time providing a professional presentation of the values for a large
audience. The output data of the Fronius IG can be displayed on up to 10 Public Dis-
plays at the same time.
The Public Display is attached to the photovoltac system via LocalNet. The Public
Display Card required for this purpose is integrated into the Public Display. Two RS-485
ports are provided to attach to the system. The DatCom cable also supplies the required
power, thus removing the need for a separate power source for the Public Display.
LocalNet is the basic communication path between the Public Display and Fronius IG

LocalNet basics

inverter. LocalNet is a data network that allows data to be exchanged between Fronius
IG inverters and any DatCom components. The LocalNet data network is a bus system
with a ring topology. A single wire is required to allow the inidividual components to
communicate. This reduces the wiring overhead to a minimum.
System require- -
ments -
-

Repairs

Any repairs to the FRONIUS IG and DatCom components must be performed by FRO-
NIUS trained service technicians.
Warning! Improper use can cause serious injuries to personnel and damage to
equipment. Do not attempt to use the functions until you have read and under-
stood the following documentation:
- this Operating Manual
- any operating manuals for system components, especially concerning
safety at work requirements
The photovoltaic system must comprise a data logger
Your Fronius IG inverter must be fitted with a ComCard
The „Fronius IG.access" software must be installed
3
