AXIS 210/210A/211/211A Installation Guide
DC-Iris control cable
(AXIS 211/211A)
External microphone/line input
(AXIS 210A/211A)
Note:
Depending on the product version of your AXIS 210/210A/211/211A, you will see
one of two different types of I/O ternminal connectors. See I/O terminal connec-
tor, on page 15.
Dimensions
AXIS 210/210A:
HxWxD = 38 x 88 x 157mm (1.5" x 3.4" x 6.2")
Weight (AXIS 210) = 305g (0.67lb) excl. power supply
Weight (AXIS 210A) = 325g (0.72lb) excl. power supply
AXIS 211/211A:
HxWxD = 38 x 95 x 178mm (1.5" x 3.7" x 7")
Weight = 345g (0.76lb) excl. power supply
Rear panel
Audio output
(AXIS 210A/211A)
4 3 2 1
I/O terminal
connector
Power connector
Network connector and PoE
(AXIS 210A/211/211A)
