PM5 Menu Map
Sample Display
Total elapsed time.
Total meters rowed or skied.
Average pace (in time) per
500m. This is the average
for your entire workout.
Split meters. The number
of meters rowed or skied in
a given distance or time. In
Just Row / Just Ski splits are
five minutes long.
UNITS
Push at any time to change units between Meters
(m), Pace (time/500m), Watts and Calories (cal).
PM5 Views
Back View of PM5
Battery cover
Reset button
More Information
Using a Heart Rate Monitor:
The PM5 will receive and display heart
rate data directly from a Bluetooth Smart,
or ANT+ ™ HR chest belt.
Suunto™, Garmin
®
See More Options for set up.
WARNING!
Heart rate monitoring systems may be inaccurate . Over-exercising
may result in serious injury or death . If you feel faint, stop exercising immediately .
(Visit concept2.com/PM5 for more information.)
Memory
USB flash drive port
Race system jacks (2)
USB-B
USB cable (optional)
to computer or
phone/tablet
3
Strokes per minute (s/m).
Pace (in time) per 500m (calculated each stroke).
Your pace is the amount of time it takes to row
or ski 500m. A smaller time is faster.
Heart rate
(Optional. Requires additional chest belt.)
Projected meters in 30 minutes if the current
average pace is maintained.
MENU
Push to power up the PM, display the
previous menu or save workout results.
DISPLAY
Push at any time to change display between All Data, Force
Curve, Paceboat/Pace Skier, Bar Chart, and Large Print.
Bottom View of PM5
Cleaning the PM
Use a cloth lightly dampened with water
only. Do not spray with a cleaner or leave
in the rain.
Troubleshooting
Visit concept2.com/pm5.
Remove D Cell (LR20)
batteries from the PM5
if monitor will not be
used for a period of four
months or more.
D
D
Sensor cable
to flywheel
