DISPLAY AND KEY EXPLANATION

LED display / channel 1-5
1
Flashes during the
programming�
open button
2
Shutter/awning moves
upwards/extends�
stop button
3
Stops the up/down
movement of the
tubular motor�
close button
4
Shutter/awning moves
downwards/retracts�
channel selection button
5
This button can be used to
select the desired channel�
Labeling fields
programming button
6
On/off switching of the
programming mode� The
button is located in the
battery compartment on the
rear side�
Battery compartment
2x (AAA)
Front side
Rear side
