OWNER'S MANUAL
4. TECHNICAL SPECIFICATION
• Operating voltage: 100-240 VAC or 12 VDC
• Rated power: =< 3 W (220 VAC power supply)
• Warm-up time: 3-5 minutes
• Alarm level: 10%LEL ±5% LEL of natural gas, 150 PPM
± 80 PPM of CO
• Alarm indicator: corresponding red LED flash
• Malfunction indicator: yellow LED on & beeper long-
buzz
• Alarm sound: >= 75 dB (within 1 meter)
• Operating temperature: -10ºC to 50ºC
• Environmental humidity: =< 95% RH
• Installation mode: Wall mounted
• Alarm output: Relay output/sound & flash alarm
• Execute criterion: GB15322.2-2003
5. INSTALLATION
1. Please ensure whether the induced gas is heavier or
lighter than air. The heavier gas is e.g. LPG. The lighter
gases: carbon monoxide, natural gas, manual coal gas,
marsh gas, etc.
2. Choosing the suitable position to install the detector
according to the gas specific gravity. Detecting the gas
heavier than air: Installation height from floor: 0.3-1.0
m, semi diameter to gas source: < 1,5 m; Detecting the
gas lighter than air: Installation height from ceiling: 0.3
-1.0 m, semi -diameter to gas source: <1.5m (refer to the
following image).
15
EN
