Digital Timer VTE
1. Safety information
To be fi tted by qualifi ed electricians only, observing all standard
national installation regulations. No work is to be carried out on the
timer while it is live. It is essential, therefore, that the main
distribution line is switched off.
Check to make sure the connecting cable is not live!
All warranty claims shall be null and void in the event of any damage or
losses caused by failure to observe these operating instructions.
We accept no liability for any consequential damage or losses caused
by improper use of the timer or by failure to observe the safety advice. In
such cases all warranty claims shall be null and void. For reasons of safety
and CE approval, no unauthorised conversion and/or modifi cation of the
LightBoy Digi Timer VTE is allowed.
2. Correct use
The LightBoy Digi Timer VTE is designed for fi tting in fuse boxes on
35 mm top-hat rails. The switching contact is dry, allowing a wide variety of
potential applications.
3. Installation
Fit the LightBoy Digi Timer VTE onto the industry standard
rail in the fuse box (illustration A). Attach the consumer unit to be
switched on/off onto terminals 3 and 4 (illustration B). Attach the
power supply to terminals 1 and 2 (illustration B). Replace the terminal
box cover and switch back on the main distribution fuse.
4. Using the timer for the fi rst time
The power failure backup needs about 5 minutes to charge up for
the fi rst time. Until this has been done, the LCD display remains
blank. When fi gures appear on the display, you can start
programming. To programme the timer you need to observe the points
below and proceed in the order described.
Open fl ap. Using a ballpoint pen or similar object, press the 'Rückst.'
button. This deletes all data and puts the clock into set-up status. 'OFF'
and the time '00:00' appear on the display.

4.1 Setting the time

Press the 'Zeit' button and hold it down.
Press down the 'Std.' button until the current hour is set.
Press down the 'Min.' button until the current minute is set.
Press down the 'Tag' button until the current day of the week is set.
Release the 'Zeit' button.
5. Programming the timer
Press the 'Prog.' button once. '1' now appears as the programme number,
'Timer' as the programming mode and 'ON' for the switch-on time.
• Press down the 'Tag' button until the desired day of the week is set.
• Press down the 'Std.' button until the desired hour is set.
• Press down the 'Min.' button until the desired minute is set.
If you now press the 'Prog' button again, 'ON' is replaced by 'OFF' for the
switch-off time. You can then set this time by pressing the 'Tag', 'Std.'
and 'Min.' buttons (as for switch-on time). Memory cell 1 is now
programmed. You move to the next memory cell by pressing the 'Prog.'
button again. Repeat the above steps as for programming memory cell 1.
