After several moments, the Terminal window closes and the first WebPAM
installation dialog box appears.
5. Follow the prompts in the installation dialog box.
Log-in to WebPAM
Double-click on the WebPAM icon on your Windows desktop (right). Or,
1. Launch your Browser.
2. In the Browser address field, type in the IP address of the Host PC, as
explained below.
If you did not choose the External Security option during WebPAM
installation, use the Regular connection.
If you chose the External Security option during WebPAM installation, use
the Secure connection.
Regular Connection
• WebPAM uses an HTTP connection . . . . . . . . . . . . . . . . . . . . .http://
• Enter the Host PC's IP address . . . . . . . . . . . . 127.0.0.1 or localhost
• Enter the Port number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . :8080
• Add to launch WebPAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . /promise
Together, your entry looks like this:
http://127.0.0.1:8080/promise or http://localhost:8080/promise
Secure Connection
• WebPAM uses a secure HTTP connection . . . . . . . . . . . . . . .https://
• Enter the Host PC's IP address . . . . . . . . . . . . 127.0.0.1 or localhost
• Enter the Port number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . :8443
• Add to launch WebPAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . /promise
Together, your entry looks like this:
https://127.0.0.1:8443/promise or https://localhost:8443/promise
Note that the IP address shown above applies to a log-in at the Host PC.
When you log in over a network, enter the Host PC's actual IP address.
Opening Screen
When the opening screen appears:
1. Type admin in the Login ID field.
2. Type admin in the Password field.
3. Click the Sign in button.
13
Log-in to WebPAM
