Safety and maintenance

Cleaning the microphone
After every use, clean the microphone with a dry, soft cloth tissue and store it in a solid case or a
zipper pouch.

Technical Specifications

Capsule
Polar patterns
Tube complement
Frequency range
Sensitivity
Gain
Max. SPL (0.5% THD)
Equivalent noise level
Dynamic range
Signal-to-noise ratio
Low cut filter
Electrical impedance (floor box output)
Recommended load impedance
Connectivity
Power requirement
Dimensions
Weight
Risk of damage
Please make sure that the piece of equipment to which your microphone
and PSU will be connected fulfils the safety regulations enforced in your
country and is fitted with a ground lead.
Hand-crafted 1" diaphragm true condenser capsule
9 (omni, cardioid, figure-8 with three additional steps between each)
1x 12AU7 (ECC82)
20 – 20,000 Hz
16 mV/Pa (-36 dBV)
-12 / 0 / +12 dB, switchable
151 dB
SPL
18 dB(A)
133 dB
76 dB
40 / 80 Hz, 12 dB/Oct, switchable
30 Ohms
>2k Ohms
3-pin male XLR connector
Floor Box / PSU (included)
Microphone
Diameter 62 mm (2.44 in.) Length 240 mm (9.45 in.)
Floor Box / PSU
356 x 135 x 100 mm (14.02 x 5.31 x 3.94 in.)
Microphone
989 g (34.90 oz.)
Floor Box / PSU
3905 g (137.79 oz.)
4
