Klaxon Sonos Installationsanweisung

EN
DE
TONE TONE TYPE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
Type CPR Reference
PSS-0084 Reference 0832-CPR-0298
PSS-0089 Reference 0832-CPR-0298
Technical Data Doc.18-186213
Type A: For indoor use
(Shallow Base)
Texecom Ltd (Incorporating Klaxon Signals) St Crispin Way,
Haslingden, BB4 4PW, UK
FR NL
TONE DESCRIPTION/ APPLICATION
970Hz
800Hz/970Hz @ 2Hz
800Hz – 970Hz @ 1Hz
970Hz 1s OFF/1s ON
970Hz, 0.5s/ 630Hz, 0.5s
554Hz, 0.1s/ 440Hz, 0.4s (AFNOR NF S 32 001 )
500 – 1200Hz, 3.5s/ 0.5s OFF (NEN 2575:2000 Dutch Slow Whoop)
420Hz 0.6s ON/0.6s OFF (Australia AS1670 Alert tone)
1000 - 2500Hz, 0.5s/ 0.5s OFF x 3/1.5s OFF ( AS1670 Evacuation)
550Hz/440Hz @ 0.5Hz
970Hz, 0.5s ON/0.5s OFF x 3/ 1.5s OFF (ISO 8201 )
2850Hz, 0.5s ON/0.5s OFF x 3/1.5s OFF (ISO 8201)
1200Hz – 500Hz @ 1Hz (DIN 33 404)
400Hz
550Hz, 0.7s/1000Hz, 0.33s
1500Hz – 2700Hz @ 3Hz
750Hz
2400Hz
660Hz
660Hz 1.8s ON/1.8s OFF
660Hz 0.15s ON/0.15s OFF
510Hz, 0.25s/ 610Hz, 0.25s
800/1000Hz 0.5s each (1Hz)
250Hz – 1200Hz @ 12Hz
500Hz – 1200Hz @ 0.33Hz
2400Hz – 2900Hz @ 9Hz
2400Hz – 2900Hz @ 3Hz
500 - 1200Hz, 0.5s/ 0.5s OFF x 3/1.5s OFF ( AS1670 Evacuation)
800Hz – 970Hz @ 9Hz
800Hz – 970Hz @ 3Hz
800Hz, 0.25s ON/1s OFF
500Hz – 1200Hz, 3.75s/0.25s OFF (AS2220)
CPD Number
0832-CPD-0298
0832-CPD-0298
Fire Alarm Device - Sounder
Type B: For outdoor use
(Deep Base)
Tel: +44 1706 233879
Installation Instructions
ES PT
Essential Characteristics
Reproducibility
Operational performance
Durability
Dry Heat (operational)
Dry Heat (endurance)
Cold (operational)
Damp heat, cyclic (operational)
Damp heat, steady state (endurance)
Damp Heat, cyclic (endurance)
SO2 corrosion (endurance)
Shock (operational)
Impact (operational)
Vibration (operational)
0832
Vibration (endurance)
06 Electrostatic discharge (operational)
Radiated electromagnetic fields
(operational)
Voltage transients, fast transient bursts
(operational)
Enclosure Protection
Issue 18 (July 2013) INS533-18 Copyright © Texecom Ltd
sales@klaxonsignals.com www.klaxonsignals.com
Sonos DC Sounder
IT PL SE
DIP SWITCH
2nd
1 - 2 - 3 - 4 - 5
O - O - O - O - O 18
O - O - O - O - I 1
O - O - O - I - O 1
O - O - O - I - I 1
O - O - I - O - O 4
O - O - I - O - I 1
O - O - I - I - O 1
O - O - I - I - I 9
O - I - O - O - O 1
O - I - O - O - I 19
O - I - O - I - O 1
O - I - O - I - I 1
O - I - I - O - O 1
O - I - I - O - I 18
O - I - I - I - O 1
O - I - I - I - I 1
I - O - O - O - O 1
I - O - O - O - I 1
I - O - O - I - O 18
I - O - O - I - I 19
I - O - I - O - O 19
I - O - I - O - I 1
I - O - I - I - O 1
I - O - I - I - I 1
I - I - O - O - O 1
I - I - O - O - I 18
I - I - O - I - O 18
I - I - O - I - I 8
I - I - I - O - O 1
I - I - I - O - I 1
I - I - I - I - O 1
I - I - I - I - I 8
Declared Performance
EN54-3:2001+A1:2002
A2:2006 Subclause
5.2
5.3
5.4
5.5
5.6
5.7
5.8
5.9
5.10
5.11
5.12
5.13
5.14
5.15
5.16
5.16
5.16
5.17
DK
dBA @ 1m mA
99 17
100 16
100 16
99 10
99 15
97 9
99 12
96 5
104 10
97 10
98 8
94 17
99 13
95 9
98 13
104 30
99 14
106 41
96 13
96 8
96 7
98 11
100 17
98 9
99 14
101 36
104 36
98 6
99 16
100 6
99 4
99 13
TYPE A TYPE B
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
N/A PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
PASS PASS
