Adaptec SAS RAID Schnellstartanleitung Seite 65

Adaptec 6405T
Internal mini-SAS connector CN0
HDA mode
connector
Adaptec 6805T/6805TQ
2 internal mini-SAS connectors
HDA mode
connector
Ext. Alarm connector
Aggregate Activity
Mounting bracket
CN0 CN1
Ext. Alarm connector
Aggregate Activity
Mounting bracket
Drive Activity LED connector for CN0
Diagnostic/Activity LEDs
Daughterboard
connector
PCIe x8 connector
Drive Activity LED connector for CN0
Diagnostic/Activity LEDs
Daughterboard
connector
PCIe x8 connector
8
