Adaptec SAS RAID Schnellstartanleitung Seite 59

Adaptec 81605ZQ
2 internal mini-SAS HD connectors
Reserved
HDA mode
connector
Adaptec 7805/7805Q
2 internal mini-SAS HD connectors
Stiffener (back of board)
Mounting bracket
PCIe x8 connector
Mounting bracket
PCIe x8 connector
Ext. Alarm connector
HDA mode connector
Daughterboard
connector
2
2 internal
mini-SAS HD
connectors
Flash backup
module
connector
