Adaptec SAS RAID Schnellstartanleitung Seite 64

Adaptec 6405E
Adaptec 6805E
Mounting bracket
Activity connector for CN0
Mounting bracket
Activity connector for CN0/CN1
HDA mode connector
Ext. Alarm connector
PCIe x4 connector
HDA mode connector
Ext. Alarm connector
Aggregate Activity
PCIe x1 connector
Aggregate Activity
7
Internal mini-SAS
connector CN0
CN1
CN0
2 internal mini-SAS
connectors
