4.3 Mapping channel 9

the mapping channel split the circular patterns from pattern channel to different LED segments.

4.4 Pattern Mode channel 10

Is an overall channel for mapping, pattern und pattern speed. The pattern mode controls if a
effect is fade, switch, static or a pixel flash. Also a macro area helps fast programming.

4.5 Pattern / Pattern speed channel 11/12

This channel provides 7 increasing, decreasing and random patterns and can controlled by
speed and direction with the pattern speed channel. Without mapping channel, the patterns run
in circular form. The pattern mode as overall controls the kind of running.

4.6 Color spread channel 13

This channel generates an indexable and rotable color spread on the foreground color of the
running effect.

4.7 Sparkle / Sparkle speed channel 14/15

This channel offers a unique sparkling effect additional with dimmer and zoom channel. The
beam is splitted to the ground colors of the beam depending on the intensity of the channel va-
lue. That means full colors get in sparkling forms to fade in and fade out effects. A mixed color
is splitted to the ground colors.
- 38 -
