2.0 Channel assignment

2.1 FIXTURE MODE „Standard"
The A8 TW offers 5/3 different channel options. With PERSONALITY -> FIXTURE MODE (selection between
Standard or Extension mode) and with DMX MODE (selection of S8, S16, C8, C16 and E8 respectively M1, M2,
M3) you can select the different channel options. The selected mode will be displayed in the main menu.
Standard 8 Bit
(S8)
Channel 1
Pan
Channel 2 Pan fine
Channel 3 Tilt
Channel 4
Tilt fine
Channel 5
Control
Channel 6 Shutter
Channel 7 Dimmer
Channel 8
Zoom
Channel 9 Pattern
Channel 10 CTC
Channel 11 Fixed white
Channel 12 Pan/Tilt speed
Channel 13 Effect speed
Channel 14 Blackout move
Channel 15 Cold white
Channel 16 Warm white
Channel 17
Channel 18
- 24 -
Standard 16 Bit
(S16)
Pan
Pan fine
Tilt
Tilt fine
Control
Shutter
Dimmer
Zoom
Pattern
CTC
Fixed white
Pan/Tilt speed
Effect speed
Blackout move
Cold white
Cold white fine
Warm white
Warm white fine
Compressed 8 Bit
(C8)
Pan
Pan fine
Tilt
Tilt fine
Control
Shutter
Dimmer
Zoom
Pattern
CTC
Fixed white
Cold white
Warm white
Compressed 16 Bit
(C16)
Pan
Pan fine
Tilt
Tilt fine
Control
Shutter
Dimmer
Zoom
Pattern
CTC
Fixed white
Cold white
Cold white fine
Warm white
Warm white fine
