Der minimale Biegeradius für alle Top View (TV) und Side View (SV) Produkte von 15 cm darf
nicht unterschritten werden.
Für die Befestigung der Leuchte ist das mitgelieferte Klebeband vorgesehen. Zudem können
auch Halteklammern und Montageprofiele verwendet werden.
Befestigung:
Kelebeband
halteklammern
Profile
Temperaturbedingt ergeben sich Längenausdehnungstoleranzen von bis zu +/- 5 mm. In der
Breite von +/- 1 mm.
Aufgrund der Längenausdehnung darf die Leuchte nicht über den Stoß zweier Montagepro-
file installiert werden, um Schereffekte zu vermeiden, welche die Leiterplatte im Inneren der
Leuchte beschädigen können.
Bitte beachten Sie zusätzlich die Sicherheits- und Montagehinweise der VarioLED™ Flex Pro-
dukte auf Seite 534 ff des LED Linear Systemkatalogs.
It is up to the consumer to ensure that an adequate intake of loads is guaranteed.
Power supply units used for operation should ensure the following basic protection and safety
features:
• Short-Circuit Protection
• Overload Protection
• Overheat Protection
• SELV equivalent (Safety Extra Low Voltage)
• Class 2
The electrical feed-in is always conducted between a female plug of type VarioCon Female and
the fixture-integrated connector.
Best temperature for assembly is between +18 ºC and +35 ºC (64 °F to 95 °F)
The installation surface must be dry and clean.
Surface must be free of dust, grease, oil or separating agents.
Lightly adhering coatings must be removed. For cleaning use clean cloth and material-compli-
ant detergents like Isopropanol
Pressure to adhere should be between 10 – 15 N/cm2 (65-97 N / in
For assembly of the products which are longer than 2m (78.74") carefully handling is abso-
lutely necessary.
The minimal bending radius for all Top View (TV) / Side View (SV) products of 15 cm.(5.9")
should not be exceeded.
For the installation of the luminaire the included adhesive tape is provided. In addition, holding
clips and mounting profile can also be used.
Attachment:
• tape
• retaining clips
• profile
Due to production, tolerances in linear expansion of up to 5 mm (0.2") have to be expected. In
width by up to +/- 1 mm ( 0,04").
Please ensure that VarioLED™ Flex VENUS is not installed over the joint of 2 profiles to avoid
shearing effect which could cause a damage to the FLEX PCB board inside the fixture.
Please notice also safety and assembly information for VarioLED™ Flex, see LED Linear system
Catalog Page 536 ff.
