Top View
Clip 50 mm
Clip 30 mm (301)
Clip 30 mm (316L)
Montage Profi l 2 m
Profi le mounting 2m (78.74")
4 m
2 m
2 m
°C \ mm
250
500
10
0.25
0.50
20
0.50
1.00
30
0.75
1.50
40
1.00
2.00
50
1.25
2.50
60
1.50
3.00
70
1.75
3.50
80
2.00
4.00
90
2.25
4.50
100
2.50
5.00
Side View
Clip 50 mm
Clip 30 mm (316L)
Profi le mounting 2m (78.74")
2 m
2 m
2 m
2 m
VENUS Length (mm @ 21°C)
1.000
2.000
3.000
4.000
1.00
2.00
3,00
4.00
2.00
4.00
6.00
8.00
3.00
6.00
9.00
12.00
4.00
8.00
12.00
16.00
5.00
10.00
15.00
20.00
6.00
12.00
18.00
24.00
7.00
14.00
21.00
28.00
8.00
16.00
24.00
32.00
9.00
18.00
27.00
36.00
10.00
20.00
30.00
40.00
Clip 30 mm (301)
Montage Profi l 2 m
Leuchte / Lamp
Profi l / Contour
5.000
6.000
7.500
5.00
6.00
7.50
10.00
12.00
15.00
15.00
18.00
22.50
20.00
24.00
30.00
25.00
30.00
37.50
30.00
36.00
45.00
35.00
42.00
52.50
40.00
48.00
60.00
45.00
54.00
67.50
50.00
60.00
75.00
S. 10
Zur Befestigung der Produkte empfehlen wir auch
unsere Halteklammern.
As a further fi xation method we recommend our
aluminum VarioClips:
VarioClip VENUS TV 50 mm
•
Art.-Nr.: 13000010–01
14,5 mm x 18,5 mm x 50mm
Aluminium (Aluminum)
•
VarioClip TV 30 mm 301
Art.-Nr.: 13000033–01
19 mm x 18,5 mm x 30mm
Edelstahl (stainless steel)
•
VarioClip TV 30 mm 316L
Art.-Nr.: 13000050
6,5 mm x 21,5 mm X 30mm
Edelstahl (stainless steel)
•
VarioClip VENUS SV 50 mm
Art.-Nr.: 13000011–01
19,5 mm x 12 mm x 50mm
Aluminium (Aluminum)
•
VarioClip SV 30 mm 301
Art.-Nr.: 13000038
23,5 mm x 12 mm x 30mm
Edelstahl (stainless steel)
VarioClip SV 30 mm 316L
•
Art.-Nr.: 13000051
23,5 mm x 15,5 mm x 30mm
Edelstahl (stainless steel)
Die Halteklammern sind auch als 2 m lange Profi l-
schiene erhältlich.
The holding clips are also available as a profi le of
2m (78.74") length.
Hinweis: Die Leuchten dürfen nicht über den Stoß
zweier Montageprofi le installiert werden, um
Schereffekte zu vermeiden, welche die Leiterplat-
te im Inneren der Leuchte beschädigen können.
Note: The luminaire must not be installed over the
joint of two mounting profi les, in order to avoid
shear effects that can damage the circuit board
inside the luminaire.
Die Leuchten dehnen sich, abhängig von der
Temperatur, aus. Bei Einsatz von VENUS, PHO-
BOS, SKYLLA und NIKE in Umgebungen mit stark
schwankenden Temperaturen berücksichtigen Sie
bitte diese Ausdehnung vor der Montage. Es sollte
daher eine größere Nut eingeplant und die Stoß-
an-Stoß-Montage vermieden werden.
Produktionsbedingt ergeben sich Längenausdeh-
nungstoleranzen. (Siehe Tabelle)
Depending on ambient temperature VENUS, PHO-
BOS, SKYLLA und NIKE are expanding. In case of
installation in ambient with high altering tempe-
ratures please consider expansion before assem-
bly. A major groove should therefore be planned,
as well as the end-to-shock mounting should be
avoided.
Due to production, tolerances in linear expansion.
(see table)
