1

English

1.1

Description

The WPS600C hydraulic pressure transducer gives you quick and accurate pressure
analysis of hydraulic systems.
It offers the following features:
• high resolution and accuracy
• zero adjustment
two pressure ranges:
▪
▪ 600 bar / 60 MPa / 8700 psi
▪ 60 bar / 6 MPa / 870 psi
Compatible fluid types
The WPS600C is designed for use with hydraulic oils only. Do not use it with gasses or
any other type of liquid.
1.2

The parts of your WPS600C pressure transducer

Charging indicator
The indicator lights up when
the battery is charging.
Low battery indicator
The indicator lights up when the
power is on but the battery is low.
Range indicator
The indicator shows if the
range is selected.
DO187-9
User's Guide
Power button
Press once to switch on.
Press once again to switch
off. Conserve battery
power by keeping the unit
switched off when not in
use.
Battery fault indicator
The indicator lights up if
there is a problem with the
battery
Range buttons
Press a button to select the
indicated range.
Press and hold both buttons
to calibrate the transducer.
1
