Technical data

Versions
Power
Speed
Air consumption
Maximum pressure
Machine weight

Scope of delivery

Machine complete with carbide tipped cutter
Collet chucks 8 mm, 6mm,
Set of tools
Manual
Accessories
Base plate 100 mm for Profila E plus with gap
Base plate 100 mm for Profila E plus without gap
Base plate 100 mm for Profila P2/Pro plus without gap
Base plate 100 mm for Profila Pro plus with gap
Spiral hose d = 12 mm
Spiral hose d = 8 mm
Applications
- for milling of edges and edge bands in wood, melamine, veneer, PVC
- for flush milling of edges and wood edges
- for champfering and rounding of panels

Maintenance and repairs

Electric motor:
- Keep air vents of the machine clean
- Blow out the machine from time to time
- Reparis of electrical tools must be undertaken by trained personel only
- Use original parts only. Parts which are not described are only to be changed or modified by the manufacturer.
Pneumatic motor:
- The machine was well lubricated to protect from humidity during transport. Therefore let the machine run for a few
minutes before first use, until it doesn't leak oil anymore
12
Profila E plus
740 W (230 V)
31'000 min -
1
-
-
1.8 kg
¼"
Profila P2
300 W
21'000 min -
1
150 l/min
max. 6.5 bar
0.9 kg
Art. No.
121982
121983
121984
121987
251953
251957
Profila Pro plus
400 W
22'000 min -
1
180 l/min
max. 6.5 bar
1 kg
