RUSTA 624013410101 Gebrauchsanleitung Seite 6

ENG
7. To continue extending the system,
go back to the T-coupling's third
coupling (3), the one that now has
no hose attached to it.
8. Attach a hose of the required length
up to the next location and follow
the steps above.
Continue building up the system
until all the locations have at least
1 dripper.
9. IMPORTANT! The system must
always end with a dripper.
JOINT COUPLINGS
2 Joint couplings are supplied to al-
low you to expand the system or to
construct a longer hose with fewer
drippers.
MIST NOZZLES
2 mist nozzles are supplied for use in
greenhouses, etc. where the irrigation
is from the top with wider distribution.
These can easily be attached using
cable ties, for example, (not included).
